Dimensions & Specifications (GB/T 845 / ISO 7049)
Every row below is a starting point for the customizer above — pick any size and the drawing will redraw to that row.
Size
Nominal diameter (mm)
Pitch (mm)
Length L (mm)
Head diameter dk (mm)
Head height k (mm)
Reference standard
ST2.2
2.2
0.8
9.5
4.2
1.4
ISO 1481 / GB/T 845
ST2.9
2.9
1.1
13
5.6
1.7
ISO 1481 / GB/T 845
ST3.5
3.5
1.3
16
6.9
2.1
ISO 1481 / GB/T 845
ST3.9
3.9
1.3
16
7.5
2.3
ISO 1481 / GB/T 845
ST4.2
4.2
1.4
19
8.2
2.5
ISO 1481 / GB/T 845
ST4.8
4.8
1.6
25
9.5
2.9
ISO 1481 / GB/T 845
ST5.5
5.5
1.8
32
10.9
3.3
ISO 1481 / GB/T 845
ST6.3
6.3
1.8
38
12.5
3.8
ISO 1481 / GB/T 845
