Round Head Solid Rivet — GB/T 867 / DIN 660 (Series 097) — GB/T 867 / DIN 660
Round Head Solid Rivet — GB/T 867 / DIN 660 (Series 097) to GB/T 867 / DIN 660. Full dimensional table, materials, finishes and quotation. 8 sizes listed.
Technical Drawing
Customize the parameters below — every spec field is editable, and the drawing redraws to match the values you choose. Changing the size will snap the other fields to that size's standard values; you can then override any individual value.
Sends the selected values to the quote form below.
Request a Quotation for Round Head Solid Rivet — GB/T 867 / DIN 660 (Series 097)
Tell us the size, material, finish and quantity you need for Round Head Solid Rivet — GB/T 867 / DIN 660 (Series 097) (GB/T 867 / DIN 660) and our team will respond within one business day. Click "Request this configuration" on the drawing above to send the parameters you just chose straight into this form.
Dimensions & Specifications (GB/T 867 / DIN 660)
Every row below is a starting point for the customizer above — pick any size and the drawing will redraw to that row.
Nominal diameter (mm)
Length L (mm)
Head diameter dk (mm)
Head height k (mm)
Material
Reference standard
2.5
8
5
1.6
Aluminum
GB/T 867 / DIN 660
3
10
6
1.9
Aluminum
GB/T 867 / DIN 660
4
16
8
2.5
Carbon steel
GB/T 867 / DIN 660
5
20
10
3.1
Carbon steel
GB/T 867 / DIN 660
6
25
12
3.8
Carbon steel
GB/T 867 / DIN 660
8
32
16
5.0
Carbon steel
GB/T 867 / DIN 660
10
40
20
6.3
Carbon steel
GB/T 867 / DIN 660
12
50
24
7.5
Carbon steel
GB/T 867 / DIN 660
Round Head Solid Rivet — GB/T 867 / DIN 660 (Series 097) conform to GB/T 867 / DIN 660. As rivets, they are specified by the dimensions in the table below; this page also covers materials, finishes and typical uses.
What Are Round Head Solid Rivet — GB/T 867 / DIN 660 (Series 097)?
Round Head Solid Rivet — GB/T 867 / DIN 660 (Series 097) are rivets defined by GB/T 867 / DIN 660. They are selected by thread size and the dimensional characteristics shown below, and are available in a range of materials and finishes to suit the application and environment.
CAD Source Reference
This product page corresponds to the source drawing file 055 半圆头铆钉gb867__圆头铆钉.svg. Its illustration is rebuilt in JavaScript as a simplified continuous-line technical schematic rather than embedding the original traced SVG.
Materials & Finishes
Common materials include carbon steel (typically zinc plated or hot-dip galvanized), alloy steel in property classes 8.8, 10.9 and 12.9, and stainless steel A2 (304) or A4 (316) for corrosion resistance. Specify the material, property class and surface finish appropriate to your load and environment.
Typical Applications
Permanent joints in sheet metal, enclosures, ductwork and bodywork, including blind (single-side) access.
Round Head Solid Rivet — GB/T 867 / DIN 660 (Series 097) are stocked and supplied to order. Pricing starts from approximately US$0.020 per piece for standard sizes in carbon steel; final pricing depends on size, material, finish and order quantity (MOQ applies). Submit your exact configuration with the quote form above.
Frequently Asked Questions
Which standard governs Round Head Solid Rivet — GB/T 867 / DIN 660 (Series 097), and how are they driven?
Round Head Solid Rivet — GB/T 867 / DIN 660 (Series 097) are manufactured to GB/T 867 / DIN 660 and use the standard drive for this product family. The dimensional values on this page follow that standard.
What sizes are available for Round Head Solid Rivet — GB/T 867 / DIN 660 (Series 097)?
The table on this page lists 8 sizes for Round Head Solid Rivet — GB/T 867 / DIN 660 (Series 097), ranging from 2.5 to 12. Sizes outside the table can be quoted on request.
In which materials are Round Head Solid Rivet — GB/T 867 / DIN 660 (Series 097) supplied?
Round Head Solid Rivet — GB/T 867 / DIN 660 (Series 097) are supplied in aluminum, steel and stainless, with finishes including zinc plating, hot-dip galvanizing and black oxide. Choose material and finish to suit the load and the service environment for Round Head Solid Rivet — GB/T 867 / DIN 660 (Series 097).
How do I request a quotation?
Use the parametric drawing on this page to set the exact configuration (size, material, finish) and click "Request this configuration" — a specialist from engineeringhardware.com will respond within one business day.
