Thrust Bearing — ISO / DIN (Series 127) — ISO / DIN
Thrust Bearing — ISO / DIN (Series 127) to ISO / DIN. Full dimensional table, materials, finishes and quotation. 9 sizes listed.
Technical Drawing
Customize the parameters below — every spec field is editable, and the drawing redraws to match the values you choose. Changing the size will snap the other fields to that size's standard values; you can then override any individual value.
Sends the selected values to the quote form below.
Request a Quotation for Thrust Bearing — ISO / DIN (Series 127)
Tell us the size, material, finish and quantity you need for Thrust Bearing — ISO / DIN (Series 127) (ISO / DIN) and our team will respond within one business day. Click "Request this configuration" on the drawing above to send the parameters you just chose straight into this form.
Dimensions & Specifications (ISO / DIN)
Every row below is a starting point for the customizer above — pick any size and the drawing will redraw to that row.
Bore d (mm)
Outer diameter D (mm)
Total height H (mm)
Dynamic axial load Ca (kN)
Limit speed (rpm)
Reference standard
10
24
9
9.65
4000
ISO 104 / GB/T 301
15
28
9
11.5
3800
ISO 104 / GB/T 301
20
35
10
17.0
3200
ISO 104 / GB/T 301
25
42
11
22.0
2800
ISO 104 / GB/T 301
30
47
11
27.0
2400
ISO 104 / GB/T 301
40
60
13
42.5
2000
ISO 104 / GB/T 301
50
70
14
52.0
1700
ISO 104 / GB/T 301
60
85
17
70.0
1500
ISO 104 / GB/T 301
80
105
19
93.0
1200
ISO 104 / GB/T 301
Thrust Bearing — ISO / DIN (Series 127) conform to ISO / DIN. As bearings & bushings, they are specified by the dimensions in the table below; this page also covers materials, finishes and typical uses.
What Are Thrust Bearing — ISO / DIN (Series 127)?
Thrust Bearing — ISO / DIN (Series 127) are bearings & bushings defined by ISO / DIN. They are selected by thread size and the dimensional characteristics shown below, and are available in a range of materials and finishes to suit the application and environment.
CAD Source Reference
This product page corresponds to the source drawing file 072 推力球轴承gb301__推力轴承.svg. Its illustration is rebuilt in JavaScript as a simplified continuous-line technical schematic rather than embedding the original traced SVG.
Materials & Finishes
Common materials include carbon steel (typically zinc plated or hot-dip galvanized), alloy steel in property classes 8.8, 10.9 and 12.9, and stainless steel A2 (304) or A4 (316) for corrosion resistance. Specify the material, property class and surface finish appropriate to your load and environment.
Typical Applications
Supporting rotating shafts and reducing friction in machinery, drives and equipment.
Thrust Bearing — ISO / DIN (Series 127) are stocked and supplied to order. Pricing starts from approximately US$1.50 per piece for standard sizes in carbon steel; final pricing depends on size, material, finish and order quantity (MOQ applies). Submit your exact configuration with the quote form above.
Frequently Asked Questions
Which standard governs Thrust Bearing — ISO / DIN (Series 127), and how are they driven?
Thrust Bearing — ISO / DIN (Series 127) are manufactured to ISO / DIN and use the standard drive for this product family. The dimensional values on this page follow that standard.
Which sizes of Thrust Bearing — ISO / DIN (Series 127) does engineeringhardware.com supply?
The table on this page lists 9 sizes for Thrust Bearing — ISO / DIN (Series 127), ranging from 10 to 80. Sizes outside the table can be quoted on request.
In which materials are Thrust Bearing — ISO / DIN (Series 127) supplied?
Thrust Bearing — ISO / DIN (Series 127) are supplied in carbon steel and stainless, with finishes including zinc plating, hot-dip galvanizing and black oxide. Choose material and finish to suit the load and the service environment for Thrust Bearing — ISO / DIN (Series 127).
How do I request a quotation?
Use the parametric drawing on this page to set the exact configuration (size, material, finish) and click "Request this configuration" — a specialist from engineeringhardware.com will respond within one business day.
