8 catalogued sizes. Pick any row and the technical drawing redraws to it.
Needle Roller Bearing are catalogued in bore 8-40 mm, with od 15-50 mm, wide 12-20 mm. 8 sizes are held in the table below, and the technical drawing redraws to whichever row you select.
Bore
8-40 mm
OD
15-50 mm
Wide
12-20 mm
Catalogued sizes
8
Dimensions are nominal values from the governing standard. Confirm the tolerance class for your application before ordering.
Customize the parameters below — every spec field is editable, and the drawing redraws to match the values you choose. Changing the size will snap the other fields to that size's standard values; you can then override any individual value.
Dimensioned line drawing of 8 Needle Roller Bearing — ISO / DIN (Series 133). Side view and top view, drawn to the dimensions in the table below and redrawn for any size selected.
Outer diameter D (mm)
15
Width B (mm)
12
Dynamic load C (kN)
7.2
Opens a short step to confirm the exact specification before you enter contact details.
Request a Quotation for Needle Roller Bearing (Series 133)
Click “Request this configuration” under the drawing to confirm the exact specification, then add your contact details. You can also send the request without a specification — but only an accurate selection gets an accurate quote.
Dimensions & Specifications (ISO / DIN)
Every row below is a starting point for the customizer above — pick any size and the drawing will redraw to that row.
Bore d (mm)
Outer diameter D (mm)
Width B (mm)
Dynamic load C (kN)
Reference standard
8
15
12
7.2
ISO 1206 / GB/T 309
10
17
12
8.3
ISO 1206 / GB/T 309
12
19
12
9.65
ISO 1206 / GB/T 309
15
23
12
12.5
ISO 1206 / GB/T 309
20
28
16
18.7
ISO 1206 / GB/T 309
25
33
16
22.8
ISO 1206 / GB/T 309
30
40
20
33.0
ISO 1206 / GB/T 309
40
50
20
42.5
ISO 1206 / GB/T 309
Needle Roller Bearing — ISO / DIN (Series 133) conform to ISO / DIN. As bearings & bushings, they are specified by the dimensions in the table below; this page also covers materials, finishes and typical uses.
What Are Needle Roller Bearing — ISO / DIN (Series 133)?
Needle Roller Bearing — ISO / DIN (Series 133) are bearings & bushings defined by ISO / DIN. They are selected by bore diameter and the dimensional characteristics shown below, and are available in a range of materials and finishes to suit the application and environment.
CAD Source Reference
This page is generated from an original native CAD part model (SolidWorks .SLDPRT) of the needle roller bearing — iso / din (series 133) family maintained by our engineering team, covering 4 recorded size configurations. The technical drawing shown above is rebuilt parametrically from the dimensional table, so it always reflects the exact size and configuration you select. Native CAD files (STEP / SLDPRT) can be supplied with your quotation on request.
Materials & Finishes
Rolling-element bearings are supplied in through-hardened bearing steel (100Cr6 / SAE 52100) as standard, with stainless (AISI 440C) and ceramic hybrid variants for corrosive or high-speed service. The specification that matters is the tolerance class, the internal clearance and the cage and seal type — not a fastener property class.
Specification Guides
Each size, material and standard of Needle Roller Bearing — ISO / DIN (Series 133) has its own reference page with the figures for that one configuration.
Goes With
Hardware commonly specified alongside Needle Roller Bearing — ISO / DIN (Series 133).
Pricing
Needle Roller Bearing — ISO / DIN (Series 133) are supplied to order. Pricing starts from approximately US$1.50 per piece for standard bore sizes in bearing steel, open or sealed; final pricing depends on size, material, finish and order quantity (MOQ applies). Submit your exact configuration with the quote form above.
Custom manufacturing · Made to drawing
Need a needle roller bearing outside the standard range?
A non-standard bearing & bushing is quoted from the drawing; where one already exists in the catalog, the special is usually a variation on its tooling.
Minimum order from 2,000 pieces; samples within 7 days of drawing approval.
