This is the Grade 8.8 Steel build of Phillips Countersunk Self-Tapping Screw — GB/T 846 / ISO 7050 (Series 028) to GB/T 846 / ISO 7050. We cover where the grade earns its cost premium, how it holds up in service, and the sizes stocked — so you can spec it without cross-checking three datasheets.
Why Choose Grade 8.8 Steel for Phillips Countersunk Self-Tapping Screw — GB/T 846 / ISO 7050 (Series 028)
The workhorse medium-carbon alloy grade for structural joints. For phillips countersunk self-tapping screw — gb/t 846 / iso 7050 (series 028), this matters when requires plating (zinc) for corrosion protection is the primary requirement.
Mechanical & Physical Properties
| Grade designation | class 8.8 |
|---|---|
| Magnetic response | Magnetic |
| Service temperature | up to approx. +300 °C |
| Corrosion characteristic | Requires plating (zinc) for corrosion protection |
Corrosion Behavior in Service
Carbon and alloy steel phillips countersunk self-tapping screw — gb/t 846 / iso 7050 (series 028) require a coating for corrosion protection. Zinc plating (with or without passivation) is the most common; hot-dip galvanizing is used for outdoor structural service; black-oxide is mainly a tarnish-prevention finish for tool-room use.
Galvanic & Galling Considerations
For phillips countersunk self-tapping screw — gb/t 846 / iso 7050 (series 028) in steel, the dominant compatibility issue is hydrogen embrittlement at high property classes (10.9 and above) when electroplated. Plating must be followed by an appropriate baking treatment, or a non-electroplated finish (mechanical zinc, zinc flake) should be substituted.
Sizes of Phillips Countersunk Self-Tapping Screw — GB/T 846 / ISO 7050 (Series 028) Available in Grade 8.8 Steel
| Size | Pitch (mm) | Length L (mm) | Head diameter dk (mm) | Head height k (mm) | Cross recess | Countersink angle (deg) | Reference standard |
|---|---|---|---|---|---|---|---|
| M3 | 0.5 | 20 | 5.6 | 1.65 | PH1 | 90 | ISO 7046 / GB/T 819 |
| M4 | 0.7 | 25 | 7.5 | 2.2 | PH2 | 90 | ISO 7046 / GB/T 819 |
| M5 | 0.8 | 30 | 9.2 | 2.5 | PH2 | 90 | ISO 7046 / GB/T 819 |
| M6 | 1.0 | 40 | 11.0 | 3.0 | PH3 | 90 | ISO 7046 / GB/T 819 |
| M8 | 1.25 | 50 | 14.5 | 4.0 | PH3 | 90 | ISO 7046 / GB/T 819 |
| M10 | 1.5 | 60 | 18.0 | 5.0 | PH4 | 90 | ISO 7046 / GB/T 819 |
| M12 | 1.75 | 80 | 22.0 | 6.0 | PH4 | 90 | ISO 7046 / GB/T 819 |
| M14 | 2.0 | 80 | 25.0 | 7.0 | PH4 | 90 | ISO 7046 / GB/T 819 |
| M16 | 2.0 | 100 | 29.0 | 8.0 | PH4 | 90 | ISO 7046 / GB/T 819 |
| M18 | 2.5 | 100 | 33.0 | 9.0 | PH4 | 90 | ISO 7046 / GB/T 819 |
| M20 | 2.5 | 120 | 36.5 | 10.0 | PH4 | 90 | ISO 7046 / GB/T 819 |
| M24 | 3.0 | 150 | 43.5 | 12.0 | PH4 | 90 | ISO 7046 / GB/T 819 |
