Dimensions & Specifications (ISO / DIN)
Every row below is a starting point for the customizer above — pick any size and the drawing will redraw to that row.
For rope diameter (mm)
Inside length (mm)
Outside length (mm)
Material
Reference standard
4
18
28
Galvanized steel
DIN 6899 / GB/T 5974
5
22
33
Galvanized steel
DIN 6899 / GB/T 5974
6
25
38
Galvanized steel
DIN 6899 / GB/T 5974
8
32
48
Galvanized steel
DIN 6899 / GB/T 5974
10
38
58
Galvanized steel
DIN 6899 / GB/T 5974
12
45
68
Galvanized steel
DIN 6899 / GB/T 5974
16
58
88
Galvanized steel
DIN 6899 / GB/T 5974
20
72
108
Galvanized steel
DIN 6899 / GB/T 5974
24
86
128
Galvanized steel
DIN 6899 / GB/T 5974
Wire Rope Thimble — ISO / DIN (Series 155) are rigging hardware manufactured to ISO / DIN. This page lists the full dimensional range with the key specifications engineers need to select and specify them.
