Property Class 8.8 Steel Clamping Handle Screw (Short) are supplied to ISO 898-1 property class 8.8. Corrosion behaviour is requires plating (zinc) for corrosion protection, the material is magnetic, and the usable service range is commonly limited to approx. +300 °C; confirm against the coating and the load. In practice this grade is the workhorse medium-carbon alloy class for structural joints.
- Grade
- ISO 898-1 property class 8.8
- Corrosion resistance
- Requires plating (zinc) for corrosion protection
- Magnetic response
- Magnetic
- Service temperature
- commonly limited to approx. +300 °C; confirm against the coating and the load
Property values are typical for the grade. Certified mechanical test data is available on request for production orders.
Material specification page for clamping handle screw (short) in Property Class 8.8 Steel. Covers the grade designation (ISO 898-1 property class 8.8), corrosion and magnetic behavior, comparable grades and their trade-offs, and the sizes available to DIN 6336 / GN 313.
Why Choose Property Class 8.8 Steel for Clamping Handle Screw (Short) — DIN 6336 / GN 313 (Series 042)
The workhorse medium-carbon alloy class for structural joints. For clamping handle screw (short) — din 6336 / gn 313 (series 042), this matters when requires plating (zinc) for corrosion protection is the primary requirement.
Mechanical & Physical Properties
| Grade designation | ISO 898-1 property class 8.8 |
|---|
| Magnetic response | Magnetic |
|---|
| Service temperature | commonly limited to approx. +300 °C; confirm against the coating and the load |
|---|
| Corrosion characteristic | Requires plating (zinc) for corrosion protection |
|---|
Corrosion Behavior in Service
Carbon and alloy steel clamping handle screw (short) — din 6336 / gn 313 (series 042) require a coating for corrosion protection. Zinc plating (with or without passivation) is the most common; hot-dip galvanizing is used for outdoor structural service; black-oxide is mainly a tarnish-prevention finish for tool-room use.
Comparable Grades
For Clamping Handle Screw (Short) — DIN 6336 / GN 313 (Series 042), class 10.9 or 12.9 is the comparable strength step. Move up when the joint preload approaches the proof load of the current class; move down when the joint is over-specified. For corrosion-critical service, switch to stainless A2 or A4.
Sizes of Clamping Handle Screw (Short) — DIN 6336 / GN 313 (Series 042) Available in Property Class 8.8 Steel
| Thread size | Pitch (mm) | Length L (mm) | Handle length (mm) | Knob diameter (mm) | Reference standard |
|---|
| M5 | 0.8 | 20 | 45 | 28 | DIN 6336 / GN 313 |
| M6 | 1.0 | 25 | 50 | 32 | DIN 6336 / GN 313 |
| M8 | 1.25 | 30 | 60 | 40 | DIN 6336 / GN 313 |
| M10 | 1.5 | 40 | 70 | 45 | DIN 6336 / GN 313 |
| M12 | 1.75 | 50 | 80 | 50 | DIN 6336 / GN 313 |
Dimensions are independent of the material: every size above is available in Property Class 8.8 Steel.
Custom manufacturing · Made to drawing
Need this bolt in a grade that is not listed?
Grade 8 8 Steel is one of the grades the catalog describes. Material and finish are usually what drives a special — a grade the standard part is not stocked in, or a coating chosen against a salt-spray figure instead of a default. Made by cold heading or hot forging.
Minimum order from 2,000 pieces; samples within 7 days of drawing approval.
Custom bolt manufacturingSend a drawing
Applications & Industries
What Clamping Handle Screw are specified for, industry by industry. Stocked from M5 to M12.
Industries that specify Clamping Handle Screw
-
Maintenance & MRO
Stocked replacements matched to an existing property class, thread and finish.
-
Food, pharma & cleanroom
Stainless assemblies that are washed down, where the finish matters as much as the strength.
-
Machine building & OEM
The default fastener on production equipment: covers, brackets, motor mounts and sub-assemblies tightened to a specified torque.
-
Automotive & transport
Chassis, driveline and body fixings that see vibration and are assembled to a controlled preload.
-
Steel fabrication
Bolted connections in frames, enclosures, walkways and weldments, on the bench and on site.
-
Energy & infrastructure
Tower, pipework, switchgear and plant fixings specified for long service life and inspectable joints.
Typical applications
- assemblies that are dismantled for service and re-torqued
- joints where the property class is stated on the drawing
- clamping two machined faces to a calculated preload
- bolting brackets, motors and gearboxes to a frame
Service conditions to specify against
- Marine and coastal
- Available in A4 (316) stainless for chloride exposure — coastal structures, pool halls, water treatment and deck hardware, where A2 will eventually pit.
- High load
- Supplied in ISO 898-1 property classes, so the joint can be designed to a stated proof load and tightened to a calculated torque rather than by feel.
- Torque and preload
- The joint is designed around bolt tension, so lubrication, coating and the friction coefficient all change the torque figure — state them together.
Where to use something else
- Do not use a machine thread into unthreaded sheet or timber; use a tapping screw, rivet nut or insert made for that parent material.
